Modify clone parameter, how to blend between various clones.
Modify clone parameter, how to blend between various clones.
In this quick tutorial i show you how to unwrap a model in 3D coat!
Buying a GPU for GPU rendering? Read this first. I find myself answering the same questions over and over. So here is a summary of what you need to know when buying a GPU for GPU rendering. This information is valid as of writing this, I will try keep it updated as we go along.
Temporary disclaimer: The Nvidia 1080/1070 cards currently are not supported by all gpu render engines. The support is rolling out slowly, so check your specific engine before buying. Octane and Thea are both working on it. Apprantly VrayRT and redshift support them, but neither of them are available for C4D.
Nvidia. All the gpu renderers are nvidia CUDA based. This might change in the future, but right now if you want a fast stable GPU renderer you are stuck with nvidia.
[disclaimer]: don’t install geforce experience, just the drivers and update them manually. There have been reported issues with the software which you really probably don’t need.
: Getting a lot of feedback about AMD cards. and how indigo and vray support OpenCL.. In todays world and i can only write about today, because the futures change rapidly, it would be irresponsible of me to recommend people to get an AMD card for rendering. If anything it just adds another layer of complexity where it’s not needed. Get an nvidia card and you aren’t losing anything. Get an AMD card, and some engines won’t work, while others not as well as CUDA etc.. OpenCL stuff runs on Nvidia cards just fine and often better than on equivilantly priced AMD cards. But by all means do your own research.
The onboard memory of GPU cards does not stack. ie, 2x 6gb cards, can handle a 6gb scene. 1x 3gb card and 1x 6gb card, can only handle a 3gb scene. So if you have a bigger scene, you will have to disable the smaller card. And for the most part everything needs to fit on the GPU. Octane has out of core textures, which means it keeps the textures in the system ram, which helps at times, but apparently also slows down the render. And Octane has a Tiled frame buffer in system RAM since 3.x with the aim to reduce the VRAM overhead on each card. Thea has bucket rendering mode, so when you are rendering the final image the buffer doesn’t take up all the memory on the card.
Also be aware of Dual GPU video cards. Some Nvidia cards including the titans. Have 2 gpu’s on one card. Here, the memory has to be halved. It will say it has 6gb of memory on it, but its actually only 3gb per GPU. the GTX 790 is an example of a card like this.
Some cpu have less pci lanes then others. This is mostly irrelevant to GPU renderers, as long as you have at least 1 or 2 lanes per card you will be fine. The pci lanes is more important for games.
Once again SLI is irrelevant to GPU rendering. You should not install the sli bridge or enable this in the options. Furthermore unlike in SLI ( which is only useful for games). GPU render engines don’t care if you have different cards working together. so you can have, 780’s and 980’s and titans all working together. Just keep in mind the memory issue i brought up earlier.
: if you game with SLI you can install the bridge and enable/disable SLI in the nvidia control panel at will. ( a comment from reddit provided this useful information)
If you are planning on putting multiple GPU into your computer, make sure they have fans that push the hot air out of the case. So either reference coolers, coolers that look like reference coolers or liquid cooled/hybrid cards.
Because as you can see above, the traditional fans just expell the hot air into any direction as long as its away from the card which means the air is being pumped into the case itself so sticks around to heat the whole shebang up. Works fine if you have 1 gpu in your case, but if you have 4 well.. not so fun..
So what you do want, is the cards with heatsinks like this to blow the hot air outside of the case.
There are lots of brands that manufacture Nvidia based cards. EVGA, MSI, ASUS and Gigabyte are the largest in the west. EVGA generally has the best reputation for their great warranties and customer support. Asus probably has the worst reputation for Customer support, but they are much loved for their prices and performance. ( I have asus, even though i got burnt with their laptop). Just you know, read the warranty terms, maybe do some googling. This stuff changes very quickly. Some brands become terrible, some get better.
Many people like to have a dedicated video card which isn’t engaged in rendering to handle the viewport and windows desktop. So they will have 3 titans for example to handle rendering and then a gtx 950 to handle the monitors. This stops your system from becoming unresponsive while rendering. While this works in most situations, you might not want to get the cheapest possible card, because cinema4D uses the card that the monitor is connected to to handle the viewport. And possible other programs do the same. C4D’s viewport isnt too stressful on the video card, most of the slow downs you will see will be cause by your CPU, but still something to keep in mind.
There are a couple of things to consider. First GPU’s come in different widths. Most of the cards you will probably be using will take up 2 slots. Some cards take up 3, but they are rare, and probably have the wrong type of heatsink on them anyway. So while you can buy motherboards with 6 or 10 PCi slots, you probably won’t be able to actually fit all the cards into it. Most cases will fit at most 3 cards, so if you want 4 cards, make sure you have a pc case, with alteast 8 pci slots on the back. Note: I’m not talking about the motherboard. the motherboard only needs 4 pci slots for 4 pci cards. ALSO a lot of these cards are really long, so make sure your case has enough clearence to fit them not only next to each other but also length wise. Sometimes the hard drive bays will get in the way.
And also related to fitting stuff in, don’t forget to make sure you have a large enough PSU. Use this website to help http://outervision.com/power-supply-calculator
So there you go, now hopefully you will be able to make a more informed decision 🙂
If you need more info about building a machine for vfx check out the other article i wrote about hardware: http://ace5studios.com/hardware/
How to make one geometry surface deform another, useful for stitches, bulges, ties, shirts etc..
Ever have trouble with those little white boxes next to the camera and render the wrong view? This video tries to clear things up a bit 🙂
Do you ever need to run various configurations of c4d on a regular basis? For example an install without plugins? Or perhaps you are beta testing a render engine, and you regularily need to switch between stable and beta version? Well here i’ll show you how to do that without duplicating your whole c4d install folder.
Cinema4D looks in 2 places for plugins/scripts/layouts etc. The first place is in the root folder of c4d. c:/program files/maxon/cinema4d or wherever you have it installed. The second is called a prefs folder. This by default lives somewhere in your “my documents” folder. and is unique to each user account on your computer. Here i will show you how to manually tell c4d which prefs folder it should look at when launching.
Make a shortcut to cinema4D in your R17 folder.
right click on it and click properties.
now in the Target field add:[ g_prefspath=”E:dropboxc4d prefs”]
without the square brackets. So mine looks like this:
Don’t forget the space before the “g_prefspath”.
Now when you open Cinema4D from that shortcut, thats where its going to get all your layouts and shortcuts and plugins from.
You can make as many of these shortcuts if you want. What is important is that you install your plugins into the “plugins” folder inside the prefs folder and not in your root directory. Because the root directory plugins will load all the time regardless of what c4d shortcut you click.
If you want to get your old prefs and put them there you can do that easily. By opening cinema4D from the cinema 4d.exe file. pressing ctrl+e, and clicking the “open preference folder” button in the bottom left of the window. From there you can also check where your current open instance of C4D is getting its preferences.
Now you can rename these shortcuts to Cinema4d clean, Octane Beta, Octane stable etc..
Keep in mind that each version will have its own shortcuts and layouts. So be wary of that. maybe find a software that will sync just some of the files inside those folders, I haven’t looked into that yet.
Note: in R15 it was different, so my target path looked like this: “E:\soft\CINEMA 4D R15a\CINEMA 4D 64 Bit.exe” -homedir “E:\soft\CINEMA 4D R15a\myprefs”
Got tired of staring at the Bright white screen while reading the xparticles manual, so i made this simple CSS tweak. Just extract it to [your_c4dPath\plugins\X-Particles\manual\css]
Animations Jumping around when you parent them? Let me explain why that happens and how to address the issue.
Ha-HA! Finally it is done! Marvin rigged for Cinema4D ! Thanks for Vector from https://www.vector3d.co.uk/ for the awesome model! I just did some cleaning up on it to make it more rigging friendly.
Then i set up the rig, only added 2 facial expressions. I think facial expressions will be my next challenge.
You can ignore the errors that come up about plugins, you don’t actually need them.
This model is free for private use. There is no commercial license since its copyright property of warner Bros.
If you have trouble animating or posing him, have a look at this video, its a very similar concept:
And you can download him from here and don’t forget to tag him #marvin4d if you use him:
If you like him, don’t forget to follow me on Twitter!
Are your objects lagging or bouncing when they are not meant to? I made a video for you on how to fix it 🙂
